Description
Description：
JPRO Professional Diagnostic – Comprehensive and powerful all makes, all models, diagnostic and repair software provides service information with bi-directional functionality in one complete service
JPRO 2024 Commercial Vehicle Diagnostics Features:
Date:2024
Version：v3
Size:about 1.22GB
Languages:English
OS Requirements:Windows 10 / 11
Note:a ,Price only for ONE PC installation and activation
b,After payment you will get the downloading on the payment page,
if you can not get it,please contact us.And this item include installation guide,if you do not how to install,my tech team will install it for you by remote.
JPRO 2023 V2 Heavy Duty Truck Diagnostic Software:
✓ General Features
✓ JPRO® Heavy-Duty Features
✓ JPRO® Medium-Duty Features
✓ Education and Troubleshooting Features
✓ Reporting Features
✓ Integration Features
✓ Configuration Features
✓ Product Support Features
JPRO 2024 SYSTEM REQUIREMENTS
Supported Operating Systems
➢ Windows 7 (32 or 64-bit English, 32-bit Spanish)
➢ Windows 8 and 8.1 Pro (32 or 64-bit English, 32-bit Spanish)
➢ Windows 10 (32 or 64-bit English, 32-bit Spanish)
Hardware Requirements
➢ Minimum: 4 GB RAM, 20 GB of available hard drive space, Intel Core i3, 1024 x 768 monitor
➢ Recommended: 8 GB RAM, 20 GB of available hard drive space, Intel Core i5
➢ USB port for Noregon DLA+ or DLA+ 2.0 or port for other RP1210C-Compliant vehicle adapter
JPRO 2024 Commercial Vehicle Diagnostics Models Coverage:
Engines
✓ CAT
✓ Cummings
✓ Detroit
✓ Ford
✓ GM
✓ International
✓ Mack
✓ Mercedes-Benz
✓ Paccar
✓ Sprinter
✓ Volvo
Transmissions
✓ Allison
✓ Detroit
✓ Eaton
✓ GM
✓ Mack
✓ Sprinter
✓ Volvo
✓ ZF
ABS
✓ Bendix
✓ Ford
✓ GM
✓ Haldex
✓ Sprinter
✓ Wabash
✓ WABCO
Body & Chassis
✓ Bluebird
✓ Sprinter
✓ Sterling
✓ Freightliner
✓ Thomas Built
✓ Ford
✓ GM
✓ Western Star
✓ International
✓ Kenworth
✓ Mack
✓ Peterbilt
JPRO 2024 V2 Update Features:
Heavy-Duty Support for Cummings
• Supports reading Cummings Proprietary Fault Codes on all EPA 07 and newer Cummings engines.
• Supports proprietary sensor data on all EPA 07 and newer Cummings engines.
• Supports reading proprietary NOx sensor data on all EPA 13 and newer Cummings engines.
• Supports CummingGs CNG (compressed natural gas) engines including proprietary fault codes and sensor data.
• Bi-Directional support for Cummings engines
JPRO OFF-HIGHWAY FEATURES:
Off-Highway supports Caterpillar Off-Highway engines.
Supports SAE J1939 messages.
Ability to save and playback log files for Off-Highway specific connections.
SUPPORT FOR CATERPILLAR (OFF-HIGHWAY)
Supports reading proprietary diagnostic fault codes, event codes, and data for the following Caterpillar engines on Off-Highway vehicles:
C4.4, C6.6, C7.1, C9.3, C9.3B
JPRO HEAVY-DUTY FEATURES:
Now supports trailer diagnostics using the Universal J560 PLC Adapter combined with a DLA+ 2.0, DLA+, DLA+ 2.0 Wireless, DLA+ Wireless, or DLA+ PLC adapter.
ECU product names are now displayed instead of generic source descriptions in fault and data displays throughout the application.
GENERAL FEATURES
Only Noregon DLA+ 2.0, DLA+ 2.0 Wireless, Trailer Diagnostic Adapter, DLA+, DLA+ Wireless, and DLA+ PLC adapters are supported.
Heavy-Duty: CATERPILLAR (ON-HIGHWAY)
NEW Bi-Directional support for Caterpillar engines:
Cruise Control Speed Limits
Low Cruise Control Speed Limits, High Cruise Control Speed Limit
3126, C7, C12, C13, C15, and C18
Idle Shutdown
Idle Shutdown Time, Idle Shutdown Override
3126, C7, C12, C13, C15, and C18
Maximum Vehicle Speed Limit
Vehicle Speed Limit
3126, C7, C12, C13, C15, and C18
Heavy-Duty: Cumming
Additional Bi-Directional support for Cummins engines:
Fuel Injector Performance Test
EPA10 all ISX (12 & 15L) | EPA 13 all ISX (12 & 15L) | GHG17 all L9, X12, X15
Heavy-Duty: DETROIT DIESEL
Additional Bi-Directional support for Detroit Diesel engines:
Cylinder Cut Out:
Now supports GHG17 and newer with
engine software version: App_3105, App_3106, App_3107 and GHG17 and newer with MCM software version: mcm_0x60EF
DEF Coolant Valve Control Test
Now supports GHG17 and newer with MCM software version: mcm_0x6EF and GHG17 and newer with ACM software version: acm_0x0250
DEF Quantity Test
Now supports GHG17 and newer with ACM software version: acm_0x0250
DPF Service Regen
Now supports GHG17 and newer with engine software version: App_3105, App_3106 App_3107
Hydrocarbon Doser Purge
Now supports GHG17 and newer with MCM software version: mcm_0x06EF
Parked SCR Efficiency Test
Now supports GHG17 and newer with ACM software sersion: acm_0x0250
Performance Check Low Temp ATD
Now supports GHG17 and newer with MCM software version: mcm_0x06EF
SCR Airless Doser System (ADS) Self-Check
Now supports GHG17 and newer with ACM software version: acm_0x0250
SCR Output Component Test
Now supports GHG17 and newer with ACM software version: acm_0x0250
Heavy-Duty: PACCAR
Supports reading proprietary diagnostic fault codes for
CECU3 500 and VECU controllers.
Additional Bi-Directional support for Paccar engines:
Check Internal DEF Pump Module Heater
supported on EPA 13 all MX Engines.
