Perkins 2806F Engine Exhaust Elbow Remove and Install Procedure



This article introduces the Perkins 2806F engine Exhaust Elbowre Remove and Install

Perkins Engine ECM ECU Flash Files Collection Download

procedure Start By:

a. Remove the exhaust bellows. Refer to

Disassembly and Assembly, Flexible Exhaust Pipe – Remove and Install for the correct

procedure.

Removal Procedure

1. If necessary, remove the nitrogen oxide sensor
from elbow connection (3). Refer to Disassembly and Assembly, Nitrogen Oxide Sensor – Remove and Install for the correct procedure.
2. Loosen V-band clamp (2) and remove elbow connection (3) from turbocharger (1).

Installation Procedure

1. Ensure that all components of the exhaust elbow are free from wear or damage.

2023A& 2022A Perkins EST Electronic Service Tool Diagnostic Software Full Provide Installation Service

2. Install a new V-band clamp (2) onto turbocharger ( 1). Ensure that the V-band clamp is correctly

orientated.

3. Install elbow connection (3) onto turbocharger (1). Loosely position V-band clamp (2) onto the elbow connection and the turbocharger.

4. Install the exhaust bellows. Refer to Disassembly and Assembly, Flexible Exhaust Pipe – Remove and Install for the correct procedure.

5. Align elbow connection (3) with the exhaust bellows.

6. Tighten V-band clamp (2) to a torque of 8.5 N·m (75 lb in).

Lightly tap the V-band clamp with a soft faced

hammer to seat the V-band clamp. Refer to

Illustration 167 . Again,tighten the V-band clamp to a torque of 8.5 N·m (75 lb in). Repeat this Step 6 until the V-band clamp are correctly seated onto the turbocharger.

7. If necessary, install the nitrogen oxide sensor to elbow connection (3). Refer to Disassembly and Assembly, Nitrogen Oxide Sensor – Remove and Install for the correct procedure.
